Blue Baron Compact 45 Truck Mount Extractor with 105 Gallon Fresh Water Tank Cpt45105aq Hose Set Wand

Blue Baron Compact 45 Truck Mount Extractor with 105 Gallon Fresh Water Tank CPT45105AQ Hose Set, Wand, Water Conditioner [CPT45105AQ]

Click to enlarge

Your Price: $21,895.00
Part Number: CPT45105AQ
Quantity:
Estimated shipping cost: $ 727.00

Product Options
Shipping Surcharges:

Blue Baron Compact 45 Truck Mount Extractor with 105 Gallon Aqua Baron Sub Well Fresh Water Tank

Factory package deal truckmount extractor system for professional carpet cleaning, tile cleaning, upholstery cleaning, and restoration work. This Compact 45 package combines a powerful gas engine truck mount, high-performance blower, stainless heat exchanger system, recovery tank, fresh water tank, hose package, and wand into one complete truckmount setup.

Package Includes

Blue Baron Compact 45 truck mount extractor console
105 gallon Aqua Baron Sub Well fresh water tank
27 HP Kohler CH752-3100 air-cooled OHV twin engine with key start and Tiny Tach
4MR Sutorbilt / Gardner Denver positive displacement blower
AR high-pressure water pump
3-stage stainless Axis Point heat exchanger system
103 gallon heavy-duty marine-grade recovery tank
200 ft of 2 in crush-proof vacuum hose
25 ft x 1.5 in vacuum hose leader
200 ft blue non-marking solution hose rated 4000 PSI
Stainless commercial 2-jet carpet cleaning wand

Key Performance Features

Engine: 27 HP Kohler CH752-3100 air-cooled OHV twin engine
Blower: 4MR Sutorbilt / Gardner Denver PD blower, 435 CFM at 15 in Hg
Maximum hose reach: Up to 500 ft vacuum hose
Water pump: AR pump, 3.5 GPM, up to 3000 PSI working pressure
Heat system: 3-stage stainless Axis Point heat exchanger, up to 240 degrees F
Temperature protection: Variable temperature control and high-limit shutdown
Drive system: Reliable belt-driven design

Recovery Tank Features

103 gallon heavy-duty marine-grade recovery tank
3/16 in thick tank construction
1.25 in pump-out port
Stainless steel debris basket
EZ Flow stainless filter
Gate valve drain
Vacuum relief system
High-limit shutdown
Bi-directional tank design for easier installation

Fresh Water Tank Features

105 gallon Aqua Baron Sub Well fresh water tank
Space-saving low-profile design
Demand pump included
Filtration system included
Expansion tank included

Dimensions

Truck Mount Console	38 in H x 30 in W x 41 in D
Fresh Water Tank	43 in W x 47 in D x 12 in H
Fresh Water Tank with Console Brackets	Add approximately 2 in

Warranty Information

Kohler engine: Factory lists 3 year warranty
Recovery tank: Factory lists 5 year warranty
Frame and recovery tank: Factory advertises lifetime warranty on frame and recovery tank construction
Other parts: Factory lists 1 year warranty unless otherwise specified

Bundle Includes:

Factory Supplied
200 ft Truckmount Hose Set with 25 ft 1.5 in Vacuum Hose Leader
- Or similar

Factory Supplied
10-1460 Carpet Cleaning Wand 12in x 1.5 OD 2 Jet 1200psi Double Bend AW29 3000Psi Hose Westpak 8.600-061.0
- Or similar

Free Dealer Supplied
Steam-Brite.com Exclusive
Magnetic Clamp-On Water Softener Descaler for Truckmount & Portable Carpet Cleaning Machines 20260425 Magnetizer
No more clogged heat exchangers, improved heat transfer, Hotter water, and NO monthly descaling!

Optional Accessories

Clean Storm 20121224 200 ft Live Electric Vacuum Hose Double Reel for Truckmounted Carpet Cleaning Machines 12V All Sales Final
- Extended Warranty + No Extended Warranty
- REEL CONFIGURATION VACUUM REEL ON RIGHT SIDE
- Shipping Surcharges None Commercial Address Forklift / Loading Dock On Site No Appointment Provided

PMF U1574S, Easy Grip Tools, 4-1/2in Wide Internal Spray, 500Psi Brass Valve, 6ft Hide A Hose Hand Wand, Esteam 255-085
- Add-ons + None
- Quick Disconnect Coupler Needed .Male Brass Carpet Cleaners Style (Default) 1/4

HydroForce AS08, Injection Prespray Sprayer Pro A70109, UPC 768724753175

Hydro-Force AB24 CRW Grandi Groomer Carpet Rake Complete Rake and Stick 8.618-214.0 CA001 G180 2626-0707 71-350

Mytee TRex Jr 12 inch Rotary Power Wand Price Match Includes Air Mover Bundle 20240905

Shazaam 20170116, Carpet Cleaning Auto Detailing Start Up Chemical Package, Starter Package ChemStart

Hose Wall Buddy Corner Guard 861609 AC18 AC181 CornerG 8.697-425.0 A56578

Important Notes

Truck mount equipment normally ships by freight truck.
Professional installation is recommended.
Photos may show optional accessories, installation examples, or items not included unless specifically listed above.
Specifications, appearance, fittings, and included components are subject to change by manufacturer without notice.
Payment by wire transfer only. 85% down and 15% due before item ships in 90 days. All sales final. One year factory parts warranty excludes freeze damage and low oil damage.

Blue Baron Compact 45 truck mount extractor package with 27 HP Kohler engine, 4MR Sutorbilt blower, AR 3000 PSI pump, stainless heat exchanger, 103 gallon recovery tank, 105 gallon fresh water tank, hoses, and wand.

Some Parts Used For The Build:

Kohler 27hp Command Pro Horizontal Engine PA-CH752-3100 747cc GTIN N/A
- Or similar

Legend Brands 109100 Throttle Cable | Prochem 40-031 | Karcher 8.617-754.0 86177540 | Hydramaster 000-025-033-
Or similar

Gardner Denver 4MS-RHC-SLSGRS-SPL, Sutorbilt Legend 4MP PD 4ML Truck Mount Vac, 45 Blower Pump, GACMDSA0084
- Or similar

AR Pump RCA35G25N, Replacement Pressure Washer, 3.5 gmp 2500 psi 1750 rpm
- Or similar

Dwyer VisiFlow Meter H325 with Knob [18-808522] HydraMaster PHY074-020 000-074-020
- Or similar

General Pump PGP100906, Stainless Chemical Pulse Pump, Compatible With Prochem HydraMaster 46-056 Legend Brands 119114- Or similar
