TurboForce TH-40 Turbo Hybrid 12 Inch Tile & Grout Cleaning Spinner Wand
Professional hard surface cleaning tool for tile, grout, stone, brick, and other uneven hard surfaces. The TurboForce TH-40 Turbo Hybrid combines high-pressure spinning spray action with vacuum recovery to blast soil from grout lines while recovering dirty water at the same time. This is one of the most recognized professional tile and grout spinner wands used by carpet cleaners, tile cleaning contractors, restoration companies, and hard surface cleaning specialists.
Steambrite Advantage: Freight included, optional discounted Cobra AR50 hand detail wand available from the drop-down menu, replacement parts available, and support from a company that has sold professional cleaning equipment since 1978.
Best Uses
Ceramic tile and grout cleaning
Porcelain tile cleaning
Stone and textured hard surface cleaning
Commercial kitchens, restrooms, entryways, and high-soil areas
Residential tile floors, showers, patios, and pool areas
Brick and uneven hard surfaces when used with the proper pressure and chemicals
Why Contractors Choose the TH-40
Fast production: Cleans approximately 400 to 1000 sq ft per hour depending on soil level, grout depth, surface texture, water temperature, chemistry, and machine performance.
12 inch cleaning path: Large enough for production work while still easy to control in homes and commercial buildings.
Vacuum recovery: Helps remove dirty water while cleaning to leave floors drier than pressure washing alone.
Low profile head: Reaches under cabinet toe kicks and low clearance areas.
Hard boot and brush ring included: Lets the operator select the best ring for the surface and cleaning conditions.
Stainless steel handle and body: Built for professional daily use.
Inline filter: Helps protect spray jets from debris.
Specifications
Model
TurboForce TH-40 / TH40 / HFT-40 / Turbo Hybrid
Cleaning Width
12 inch class tool with 12-1/2 inch dome
Spray Bar
10 inch spinning spray bar
Operating Pressure
650 to 3000 PSI recommended range
Production Rate
Approx. 400 to 1000 sq ft per hour depending on surface and soil load
Vacuum Connection
1-1/2 inch vacuum hose cuff connection
Dome Height
Approx. 3-1/4 inches high
Low Clearance Reach
Can reach under cabinets as low as approx. 3-3/8 inches
Construction
Stainless steel handle/body with fiber reinforced shell covering
Included Rings
Hard boot ring and brush ring
Shipping Weight
Approx. 23 lbs
Approx. Dimensions
57 in x 21 in x 6 in
Machine Requirements
For best results, use the TH-40 with a professional tile cleaning machine, truckmount, or pressure washer/extractor system capable of supplying adequate pressure, flow, vacuum recovery, and hot water when available. Higher pressure, proper chemistry, dwell time, and heat will normally improve results on greasy grout and commercial floors.
Recommended for machines capable of 650 PSI or higher.
Works best with strong vacuum recovery and proper waste water handling.
Use defoamer when needed to protect vacuum motors and recovery systems.
Always pre-spray, allow proper dwell time, and agitate grout lines when required.
Optional Cobra Detail Wand Bundle
Use the product drop-down menu to add the optional discounted AR50 Cobra hand wand. The Cobra is useful for edges, corners, stairs, vertical surfaces, shower walls, baseboards, brick detail work, and areas where a 12 inch spinner head cannot reach.
Cross Reference / Also Known As
TurboForce TH-40
TurboForce TH40
Turbo Hybrid TH-40
HFT-40
MasterBlend 440400 / 440403 association
US Products HFT-40 association
TF-TH-EA
TURB-1108
53TTH-40
Hard Boot Ring vs. Brush Ring
Ring Type
Best For
Notes
Hard Boot Ring
Smoother tile, sealed floors, and maximum glide
Helps maintain vacuum recovery and smooth movement across many hard surfaces.
Brush Ring
Textured tile, uneven floors, grout detail, and rougher surfaces
Helps scrub and follow uneven surface profiles.
Common Add-On Items
TurboForce AR50 Cobra hand detail wand
Replacement hard boot ring
Replacement brush ring
Replacement spray jets
Replacement solution hose
90 degree swivel fittings
Tile and grout pre-spray chemicals
Grout brushes and agitation tools
Defoamer for recovery tanks
Concrete adapter and larger head upgrade options when available
Frequently Asked Questions
Can I use the TH-40 with a portable extractor?
Yes, if the portable extractor or add-on pump system provides enough pressure, flow, and vacuum recovery. The better the pressure, heat, flow, and vacuum, the better the cleaning speed and dry-down. Usually automatic waste water dump is nice since you might be processing up to 2 gallon per minute.
Does this replace hand scrubbing?
On many jobs it greatly reduces hand scrubbing, but heavy grease, deep grout lines, neglected floors, or mineral buildup may still require pre-treatment, dwell time, agitation, edge detailing, or repeat passes.
Why add the Cobra hand wand?
A 12 inch spinner is excellent for open floor areas. The Cobra hand wand is better for corners, edges, stairs, shower walls, vertical surfaces, and tight areas.
Can it clean concrete?
The TH-40 is primarily sold as a tile and grout spinner wand. Optional concrete adapters and larger head options may be available for certain applications. Always match the tool, pressure, flow, and surface to avoid damage.
Can color vary?
Yes. Tool color may vary by factory production run. Customer does not get to choose the color because boxes are not opened before shipment.
Important Use Notes
Test in an inconspicuous area before cleaning delicate stone, loose tile, cracked grout, painted surfaces, or older floors.
Do not exceed the safe pressure rating of your hoses, fittings, pump, or cleaning tool.
Keep jets clean and inspect the inline filter regularly.
Use proper personal protective equipment when working with pressure, hot water, and cleaning chemicals.
Specifications and included parts are subject to factory change without notice.
Warranty
Includes the manufacturer’s warranty on non-wear components. Wear items such as rings, jets, hoses, filters, fittings, and seals are maintenance items and may require replacement based on use, water quality, chemical exposure, pressure, and operator care.
Includes
Owners Manual and Schematics
Schematics
SEE Comparison Chart: How to Choose the right tile and grout spinner wand size
Ships in Blue , Black , and Green (Customer does not get to pick the color as we do not open the boxes)
Factory Installed Parts
Videos
VIDEO
VIDEO
VIDEO
Pictures
Optional
